Product Center

產品中心
SY5002 樣品申請
概述

The SY5002 is a low quiescent current and low dropout voltage regulator with output voltages between 0.85 V and 5.0 V capable of delivering up to 300 mA.
SY5002 has an automatic discharge function to quickly discharge VOUT when EN is disabled.
SY5002 feature Over-current protection, Thermal Shutdown and Auto-discharge function.
The SY5002 is offered in the DFN1X1-4/SOT23-5 package.

產品特性

Low dropout voltage：VDO = 196 mV (typ.) at 3.3 V-output, IOUT = 300 mA

Quiescent current: 0.55uA

Stand-by current: 0.03uA

Input voltage range: 1.8~5.5V

Fixed output voltage: 1.8V,3.3V (Other output voltage versions need to be customized)

High output voltage accuracy: ±1.0 % (1.8 V ≤ VOUT)

Output current: 300mA (MAX)

Auto-discharge

Over-current protection

Thermal Shutdown

Available in two different packages:  DFN1X1-4 and the SOT23-5 package

產品參考應用圖
應用

Wearable devices

IoT devices

Portable applications
